Timcon TMT Bars ( Grade Fe-415,500 + as per IS: 1786/'85 ) of sizes 8,10,12,16,20 mm bassed on SIP USA technology and design which guarantees the properties required by International standards.

   ۰    Bars of sizes 8 mm to 40 mm.

   ۰    Plain Rounds of sizes 8 mm to 40 mm.

   ۰    Square Bars of sizes 10 mm to 40 mm.

   ۰    FLAT BARS of 5 mm to 20 mm thick and 25 mm to 125 mm wide.

   ۰    M.S. Angles 25 x 25 x 3 to 75 x75 x 10 mm.

   ۰    Channels 40 x 32 to 100 x 50 mm.

Our Worldclass technology...

TIMCON TMT steels bars are design to guarantees the properties required by international standards. German Bst 420 S/500 S of DIN 488, British Gr. 460 of BS 4449-1988, Egyptian Standard 262/1988 Gr. 36/52 and 40/60, Fe-415, 500&550 of IS: 1 786/'85, Jis. G. 3112 1975 SD 30,35,40 & 50 Swiss to par 550 S of SIA 162, French Fe E50 of NF A35-016. High strength reinforcement bar in grades of Fe-415, 500 and 550 as per IS : 1786/'85, that achieve their properties by on-line computerised controlled thermo processing.

Our special features...

۰   Strength and Elongation

Higher strength with better elongation is a unique feature of TIMCON TMT bars. Designed to be much stronger than conventional bars, TIMCON TMT bars build a safer and stronger concrete structure with lesser quantity of steel, saving upto 14 to 19%.TIMCON TMT bars guarantee excellent weld ability, ductility and bend ability. Tapered edge of TIMCON TMT bars provide better weld ability that help in making high-strength connections with little overlap. Due to its low carbon content, these bars, can withstand bending and rebinding without any reduction in strength.











۰   Earthquake Resistance

For earthquake resistance, TMT bar structures need to have balanced stiffness, strength and ductility between its members, connections and supports. TIMCON TMT bars provide very high strengths with comparatively higher elongation values and better ductility, making them more earthquake resistant.

۰   Heat Resistance

Test result for TIMCON TMT bars, have shown no loss of strength up to 500'C.At a temperature range of 550'C to 600'C,the yield strength decreases by 20 N/sq mm only. Which is why, TIMCON TMT bars can be used easily in constructions prone to fire hazards.

۰   Corrosion Resistance

TIMCON TMT bars are more corrosion resistant than normal CTD bars. The fine layer of scale forms a protective layer, thereby preventing further corrosion. Whereas in CTD bars, this initial layer of scale falls down during twisting. Corrosion resistance can be further improved as per customer needs, by altering the material chemistry.








TIMCON TMT CHEMISTRY

TIMCON TMT PROPERTIES


    TIMCON BIS     YIELD
(min N/sq mm)
UTS
(min N/sq mm)
ELONGATION
(min %)

  Carbon max % 0.25 0.30     BIS TIMCON BIS TIMCON BIS TIMCON
  Manganese % 0.5 to 1.2 0.5 to 0.8   Fe-415 415 450 485 550 14.5 25
  Sulphur 0.05 to 0.055 0.066 to 0.060   Fe-500 500 530 545 600 12.0 20
  Phosphorus % 0.05 to 0.055 0.050 to 0.060   Fe-550 550 580 585 650 8.0 17
  Carbon equivalent 0.29 to 0.38 0.27 to 0.4

    SPECIFIC
WEIGHT
BIS
STANDARD
MARKET
STANDARD
TIMCON
TMT

    Gm/m Tolerance
Gm/m
%
Variation
Tolerance
 Gm/m
%
Variation
Tolerance
 Gm/m
%
 Variation
Savings in
terms of weight

  8 mm 395 367 to 423 ± 7 387 to 410 +4 to -2 370 to 385 -2.5 to -6 5.5 %
  10 mm 617 574 to 660 ± 7 605 to 642 +4 to -2 580 to 600 -2.75 to -6 5.5 %
  12 mm 888 844 to 924 ± 5 870 to 924 +4 to -2 850 to 865 -2.6 to -4.3 4.5 %
  16 mm 1580 1501 to 1659 ± 5 1548 to 1643 +4 to -2 1515 to 1535 -2.85 to -4 4.5 %
  20 mm 2470 2396 to 2544 ± 3 2445 to 3927 +2 to -1 2400 to 2420 -2 to -2.8 2.75 %
  25 mm 3850 3735 to 3965 ± 3 3812 to 3927 +2 to -1 3750 to 3780 -1.8 to -2.6 2.75 %
  28 mm 4830 4685 to 4975 ± 3 4782 to 4927 +2 to -1 4700 to 4740 -1.8 to -2.7 2.75 %


SAVINGS IN WEIGHT & COST OF CONSTRUCTION BY TIMCON TMT BARS


  CHARACTERISTICS TIMCON FE 415 TIMCON FE 500 TIMCON FE 550
  Design strength 415 N/sq mm 500 N/sq mm 550 N/sq mm
  Quantity required 1,000 MT 0.854 MT 0.809 MT
  % of saving in weight
over CTD 415
  14.6 % 19.15 %
